MailHeaderAnalyzer: Analyze email headers in PowerShell without network access

MailHeaderAnalyzer is a PowerShell module with two cmdlets. Get-MailHeaderAnalysis analyzes an email header: delivery chain with delays and TLS details, SPF, DKIM, DMARC, and ARC results including origin verification against your gateway’s authserv-id, DMARC alignment, Exchange Online hybrid classification, assessments from Microsoft Defender, SpamAssassin, and Rspamd, as well as anomalies such as duplicate From lines or Unicode control characters. ConvertTo-MailHeaderReport creates a report for tickets. The module works entirely offline: no DNS queries, no HTTP connections. It is the command-line version of the Header Analyzer on this website and uses the same analysis logic.

Parameter overview

Both cmdlets support the common parameters -Verbose, -ErrorAction, -ErrorVariable, -OutVariable and the others from about_CommonParameters.

Installation

Install-Module -Name MailHeaderAnalyzer -Scope CurrentUser

On a system without internet access, download the module on another computer with Save-Module -Name MailHeaderAnalyzer -Path C:\Temp and copy the MailHeaderAnalyzer folder to a directory from $env:PSModulePath, for example %USERPROFILE%\Documents\WindowsPowerShell\Modules (Windows PowerShell 5.1) or %USERPROFILE%\Documents\PowerShell\Modules (PowerShell 7). Update-Module -Name MailHeaderAnalyzer retrieves updates, and Get-Module -Name MailHeaderAnalyzer -ListAvailable displays the installed version.

Get-MailHeaderAnalysis

Analyzes an email header and returns an analysis object.

Syntax

Text (default)

Get-MailHeaderAnalysis
    [-Header] <String[]>
    [-TrustedAuthServId <String[]>]
    [<CommonParameters>]

Path

Get-MailHeaderAnalysis
    -Path <String[]>
    [-TrustedAuthServId <String[]>]
    [<CommonParameters>]

Clipboard

Get-MailHeaderAnalysis
    -FromClipboard
    [-TrustedAuthServId <String[]>]
    [<CommonParameters>]

Description

The cmdlet parses the raw header into fields, unfolds RFC 5322 folding, and decodes RFC 2047 values in the subject and addresses. From the Received lines, it builds the delivery chain in chronological order, calculates the delay at each hop, and reads the TLS version, cipher, and protocol class according to RFC 3848. From Authentication-Results, Received-SPF, DKIM-Signature and the ARC chain, it determines authentication results and assigns an origin to each authentication line (RFC 8601, section 5): evidenced if its authserv-id is listed in -TrustedAuthServId, otherwise only plausible or unsubstantiated; see AuthTrust. It also includes DMARC alignment, Exchange Online hybrid classification, spam filter assessments, and a list of anomalies.

The cmdlet performs no DNS queries and opens no network connection. Spf, Dkim, Dmarc and Arc are therefore always the receiving server’s verdict. DKIM and ARC signatures are not cryptographically verified; for the ARC chain, the cmdlet checks only its structure (ArcStructure).

Input is read tolerantly: a blank line ends the header, and any following message body is ignored. Lines without a field name and without leading whitespace, as can result from copying from client dialogs, are assigned to the preceding field. An mbox separator line From ... before the first field is skipped, and a byte order mark is removed. At most 200 Received lines are analyzed, counted from delivery onward.

Examples

Example 1

Get-MailHeaderAnalysis -FromClipboard

Analyzes the header currently in the clipboard. In Outlook for Windows, you can find the header under File, Properties, Internet headers; in Outlook on the web, under “View message details” in message options.

Subject     : Service-Report für März
From        : Beispiel Newsletter <news@example.org>
Date        : 2026-08-03 09:14:27Z
SPF         : pass
DKIM        : pass
DMARC       : pass
ARC         : -
CompAuth    : pass (reason 100)
AuthTrust   : Absent (no authserv-id, Microsoft 365 style)
Hops        : 3 (total 00:00:42)
DeliveredBy : zr0p278mb0570.chep278.prod.outlook.com
Findings    : none

Example 2

Get-MailHeaderAnalysis -Path .\nachricht.eml

Analyzes a saved message. The file may contain only the header or the complete message; the message body is ignored.

Example 3

(Get-MailHeaderAnalysis -Path .\nachricht.eml).Hops

Displays the delivery chain as a table, with the first hop first.

#   From                 IP              By                                     Protocol   TLS      Time (UTC)           Delay
-   ----                 --              --                                     --------   ---      ----------           -----
1   client.example.net   198.51.100.34   mail.example.org                       ESMTPSA    -        2026-08-03 09:14:28  -
2   mail.example.org     203.0.113.25    mx.eur02.prod.protection.outlook.com   Microsoft… TLS 1.3  2026-08-03 09:15:09  41 s
3   AM0EUR02FT056.eop…   -               ZR0P278MB0570.CHEP278.PROD.OUTLOOK.COM Microsoft… TLS 1.2  2026-08-03 09:15:10  1 s

Example 4

Get-Content -Path .\header.txt | Get-MailHeaderAnalysis | Select-Object -ExpandProperty Findings

Reads the header from a text file line by line and displays only the anomalies. -Raw with Get-Content is not required; the cmdlet assembles the lines itself.

Example 5

Get-ChildItem -Path .\export\*.eml |
    Get-MailHeaderAnalysis |
    Select-Object Source, Subject, Spf, Dkim, Dmarc, AuthTrust, HopCount,
        @{ Name = 'Findings'; Expression = { ($_.Findings.Code | Sort-Object -Unique) -join ',' } } |
    Export-Csv -Path .\auswertung.csv -NoTypeInformation -Encoding UTF8

Analyzes all messages in a folder and writes a CSV file with one row per message. The calculated column combines the finding codes.

Example 6

Get-ChildItem .\export\*.eml |
    Get-MailHeaderAnalysis -TrustedAuthServId 'mx.example.org' |
    Where-Object AuthTrust -ne 'Trusted' |
    Select-Object Source, AuthTrust, AuthServId, DeliveredBy

Lists messages whose authentication results do not originate from your own inbound gateway mx.example.org. For phishing analysis, this is an initial filter. Without -TrustedAuthServId, you can filter only for Unmatched; a forgery that also includes a matching Received line then appears as Matched and passes through the filter.

Example 7

$a = Get-MailHeaderAnalysis -Path .\nachricht.eml
$a.Hops[$a.SlowestHopIndex - 1] | Format-List Index, FromHost, ByHost, Delay

Displays the hop with the greatest delay. SlowestHopIndex is 1-based; the Hops array is 0-based.

Example 8

Get-MailHeaderAnalysis -Path .\nachricht.eml | ConvertTo-Json -Depth 6 | Set-Content .\analyse.json

Writes the complete analysis as JSON. -Depth 6 is required because Hops, DkimSignatures and Exchange are nested objects; the default value of 2 would output only their type names.

Parameters

-Header

The header as text. The parameter accepts a single string containing the entire header or multiple strings; pipeline input is collected and assembled into one header at the end, so Get-Content datei | Get-MailHeaderAnalysis works without -Raw. To analyze multiple headers separately, use -Path with multiple files.

Aliases: Text, Raw, InputObject

-Path

Path to a file containing the header or a complete .eml message. Relative paths are resolved against the current directory. The file is read with [System.IO.File]::ReadAllText: a byte order mark is honored; without a BOM, UTF-8 is used. Each file produces a separate result object; missing files generate a non-terminating error.

Aliases: FullName, PSPath, LiteralPath

-FromClipboard

Reads the header from the clipboard with Get-Clipboard -Raw. The parameter is available only on Windows; on Linux and macOS, the cmdlet terminates with an error, as it does if the clipboard is empty.

-TrustedAuthServId

The authserv-id or authserv-ids that your inbound gateway writes in Authentication-Results, for example mx.example.org. The cmdlet compares exactly, case-insensitively and without subdomains. Authentication lines with one of these IDs receive AuthTrust = Trusted, and only they are then included in Spf, Dkim, Dmarc and Arc. The same applies to the receiver= of a Received-SPF line.

The result is only as reliable as the gateway: it must remove incoming Authentication-Results lines that claim its own authserv-id (RFC 8601, section 5). Whether it does so cannot be determined from a header. If two lines with a trusted ID conflict, the cmdlet reports AuthTrustedConflict. Microsoft 365 does not write an authserv-id in its authentication line; if Exchange Online receives your mail, omit the parameter.

For an entire session, you can set the value as a default, for example in your PowerShell profile:

$PSDefaultParameterValues['Get-MailHeaderAnalysis:TrustedAuthServId'] = 'mx.example.org'

Inputs

System.String: Header lines or the entire header, bound to -Header.

System.IO.FileInfo: File objects from Get-ChildItem, whose FullName is bound to -Path.

Outputs

MailHeaderAnalyzer.Analysis: one object for each analyzed header. The properties are described in the Output object section.

Notes

The analysis text (explanations in Findings, CompAuthReasonMeaning and the meaning fields) is in English so it can be pasted unchanged into international tickets. You can display the default view in full with Format-List *.

ConvertTo-MailHeaderReport

Creates a report from an analysis object as Markdown or text.

Syntax

ConvertTo-MailHeaderReport
    [-Analysis] <Object>
    [-Format <String>]
    [<CommonParameters>]

Description

The report includes the subject, sender, date, and Message-ID; authentication results with origin and alignment; all findings; the delivery chain; the Exchange classification; and spam filter values. Unicode control characters for text direction remain visible in the report as <U+...> so they cannot enter a ticket system through the report. The last line states the module version.

Examples

Example 1

Get-MailHeaderAnalysis -Path .\nachricht.eml | ConvertTo-MailHeaderReport | Set-Clipboard

Creates a Markdown report and places it in the clipboard.

# Email header analysis

- Subject: Service-Report für März
- From: Beispiel Newsletter <news@example.org>
- Date: 2026-08-03T09:14:27Z
- Message-ID: <20260803091427.4Wq2Wx5RbTz@mail.example.org>

## Authentication

- spf: pass
- dkim: pass
- dmarc: pass
- compauth: pass (reason=100: passed authentication)
- Results without authserv-id (Microsoft 365 style)
- DMARC alignment: SPF Strict, DKIM Strict

## Delivery chain (total: 42 s)

| # | From | By | Protocol | TLS | Time (UTC) | Delay |
|---|---|---|---|---|---|---|
| 1 | client.example.net (198.51.100.34) | mail.example.org | ESMTPSA | - | 2026-08-03T09:14:28Z | - |
| 2 | mail.example.org (203.0.113.25) | mx.eur02.prod.protection.outlook.com | Microsoft SMTP Server | TLS 1.3 | 2026-08-03T09:15:09Z | 41 s |
| 3 | AM0EUR02FT056.eop-EUR02.prod.protection.outlook.com | ZR0P278MB0570.CHEP278.PROD.OUTLOOK.COM | Microsoft SMTP Server | TLS 1.2 | 2026-08-03T09:15:10Z | 1 s |

Example 2

Get-MailHeaderAnalysis -FromClipboard | ConvertTo-MailHeaderReport -Format Text

Outputs the report as text without Markdown markup, for example for emails or console logs.

Example 3

Import-Module MailHeaderAnalyzer
Get-MailHeaderAnalysis -Path 'C:\Temp\bounce.eml' | ConvertTo-MailHeaderReport -Format Text

Use in the Exchange Management Shell. If $env:PSModulePath is restricted there by Group Policy, load the module with Import-Module and the full path to the .psd1 file.

Parameters

-Analysis

The analysis object from Get-MailHeaderAnalysis. The cmdlet rejects other object types with a binding error.

-Format

The output format. Valid values:

• Markdown: Headings, lists, and the delivery chain as a table. Default.
• Text: Headings in uppercase, indented lines, and the delivery chain as a numbered list.

Inputs

MailHeaderAnalyzer.Analysis: the result of Get-MailHeaderAnalysis.

Outputs

System.String: the report, one string per analysis object.

Output object

Get-MailHeaderAnalysis returns one object of type MailHeaderAnalyzer.Analysis for each input. The default view displays the summary from Example 1; all properties are available through Select-Object, Format-List * or ConvertTo-Json.

MailHeaderAnalyzer.Analysis

MailHeaderAnalyzer.Hop

Each entry in Hops corresponds to a Received line. The order is chronological, the reverse of the header order.

AuthTrust: origin of authentication results

Any sender can write an Authentication-Results line into a message themselves, as well as a matching Received line. Therefore, the header alone cannot establish who wrote an authentication line. According to RFC 8601, section 5, only the line whose authserv-id the receiving organization recognizes as its own is authoritative, and the inbound gateway must remove incoming lines with that ID. The cmdlet implements this rule with -TrustedAuthServId. Without this parameter, it compares the authserv-id only with the by hosts in the Received chain (same domain or subdomain, always at the dot boundary, never a substring); this is a plausibility check.

If the header contains authentication lines from several origins, finding AuthMixedOrigins reports this. If an authentication line is absent but a Received-SPF line is present, its result is adopted as Spf and identified with ReceivedSpfOnly.

With -TrustedAuthServId, two findings are added: AuthNotTrusted when no authentication line has a trusted ID, and AuthTrustedConflict when two such lines report different results for spf, dmarc, arc or compauth. The second case means that at least one line did not originate from the gateway and that the gateway did not remove it. In this case, the cmdlet uses the topmost line; the header cannot determine which of the two is genuine. DKIM is excluded from this comparison because multiple signatures may legitimately have different results.

ARC chain: structure and verdict

For ARC, the cmdlet provides two separate values. Arc is the arc= result from the authoritative authentication line, i.e., the verdict of the recipient that verified the chain’s signatures. ArcStructure is the module’s own check and concerns only the structure according to RFC 8617: consecutive instance numbers i=1 through i=n (maximum 50), exactly one ARC-Seal, one ARC-Message-Signature, and one ARC-Authentication-Results per instance, plus cv=none for instance 1 and cv=pass for all subsequent instances. The module does not verify signatures; Consistent therefore says nothing about whether the chain is genuine. Deviations appear in ArcStructureIssues and finding ArcStructureInconsistent.

The details in ARC-Authentication-Results are claims by the respective forwarder. Finding DkimBrokenAfterForward therefore classifies a DKIM failure as the result of forwarding only when the recipient itself reports arc=pass and an earlier instance recorded a DKIM pass for the same domain.

DMARC alignment

SpfAlignment compares the envelope sender domain with the From domain; DkimAlignment compares the d= domain of the verified signature with the From domain. Strict means identical domain, Relaxed means the same organizational domain, and None means no match. The organizational domain is determined heuristically: the last two labels, or the last three for known multipart suffixes such as co.uk or com.au. A complete Public Suffix List is not included.

MailHeaderAnalyzer.ExchangeClassification

If the header contains X-MS-Exchange-Organization-*, X-OriginatorOrg or X-MS-Exchange-CrossTenant-* fields, the cmdlet populates the Exchange property. The meanings follow the Exchange Team article “Demystifying hybrid mail flow”; background is provided in Exchange hybrid headers: internal or external?.

MailHeaderAnalyzer.SpamAssessment

The Spam property combines assessments from known filters. Values originate from external systems and are decoded but not evaluated.

The complete list of compauth reason codes is available in Microsoft 365 compauth: Reason Codes.

Findings

The cmdlet returns anomalies as objects in Findings, each with Severity (Info, Warning, Fail), a stable Code for filters and scripts, and an explanation in Message.

How it works and limitations

The module reads what is in the header and derives what can be established without external queries. This entails several limitations:

• No cryptographic verification. DKIM and ARC signatures are not recalculated, and DNS records are not queried. Spf, Dkim, Dmarc and Arc are always the receiving server’s verdict; ArcStructure checks only the chain’s structure.
• Origin can be evidenced only with knowledge of the gateway. Without -TrustedAuthServId, AuthTrust is a plausibility check. With the parameter, the statement depends on the gateway removing foreign authentication lines using its authserv-id; the module cannot verify that.
• Only the final Received line is evidenced. The sender supplied all lines below it and can construct them arbitrarily. Attested marks this distinction; delays at earlier hops are based on the information in those lines.
• Organizational domains are heuristic. For relaxed alignment, the module uses a short list of multipart suffixes, not a complete Public Suffix List.
• AuthMechanism is only partially documented. Other than value 10, Microsoft has not published the codes; the module does not invent meanings.
• Character sets. RFC 2047 values are decoded using encodings that .NET recognizes on the respective system. Unknown character sets remain unchanged.

Privacy

A complete header contains internal host names, IP addresses, senders, recipients, and subjects. The article Analyze email headers without uploading the email explains why this information does not belong in an online tool. The same promise applies to the module as to the browser version: no network access. The module’s test suite includes a test that fails as soon as a network or DNS cmdlet appears in the source code.

Source code and versions

The source code is available under the MIT license on GitHub. The analysis logic is a port of the library also used by the Header Analyzer on this website; both share the test cases. Continuous integration tests every change with PSScriptAnalyzer and Pester on Windows PowerShell 5.1, PowerShell 7 on Windows, Ubuntu, and macOS. Releases to the PowerShell Gallery are published automatically from versioned tags; changes per version are listed in the changelog.

Version 0.2.0 of September 26, 2026 tightened the origin model following a review note from @saltyslugga: parameter -TrustedAuthServId, level Trusted, and Matched only as plausibility. The ArcValid property was removed and replaced by ArcStructure and ArcStructureIssues; scripts that evaluate ArcValid must be updated.

I accept bugs and feature requests as issues on GitHub. Please anonymize test headers before submitting bug reports; the included test cases use only example domains under RFC 2606 and addresses under RFC 5737.

Change log

• October 25, 2026: Replaced source RFC 7489 with RFC 9989, which supersedes the DMARC specification as of May 2026.
